Top Aluminium Rail for Covering Top WPC Panel in Fence This Structural Engineering Drawing Shows a Top Aluminium Rail 1800x21x24mm High For Covering Top WPC Panel >> Top Aluminium Rail / Channel 1800x21x24mm High, …
Bottom Aluminium Rail for Supporting Bottom WPC Panel in Fence This Structural Engineering Drawing Shows a Bottom Aluminium Rail / Channel 1800x21x24mm High, With L-Shaped Corner Brace at both Ends. Bottom Aluminium Rail …
WPC Panels for Fencing This Workshop Drawing Shows 20mm Thick WPC Panels for Outdoor Fencing: WPC Tongue and Groove Interlocking Panels 1800 x 160mm wide, stacked horzontally on top of each other. 20mm Thick …
Post Caps for Aluminium Posts – WPC Fence Fabrication Drawing for Fence Post Cap: Aluminium Post Caps (Square Profile). Post caps are usually made from powder-coated aluminium, WPC, PVC, HDPE, galvanized or stainless steel. …
Corner Brace L-Shaped Metal Bracket for Bottom & Top Rail – WPC Fence This Fabrication Drawing Shows a Corner Brace L-Shaped Metal Bracket Customized For a Horizontal Rail Cross Section Size 25mm Wide x 24mm Deep: Vertical Flange Height 24(2 times) = 48mm Horizontal Flange Length 24(2.5 times) = 60mm Angle Bracket Size: 2.5mm Thick …
Top Aluminium Rail for Covering Top WPC Panel in Fence This Structural Engineering Drawing Shows a Top Aluminium Rail 1800x21x24mm High For Covering Top WPC Panel >> Top Aluminium Rail / Channel 1800x21x24mm High, With L-Shaped Corner Brace at both Ends. Top Aluminium Rail for Covering Top WPC Panel, Fixed To Post Using Corner …
Bottom Aluminium Rail for Supporting Bottom WPC Panel in Fence This Structural Engineering Drawing Shows a Bottom Aluminium Rail / Channel 1800x21x24mm High, With L-Shaped Corner Brace at both Ends. Bottom Aluminium Rail for Supporting Bottom WPC Panel in Fencing, Fixed To Post Using Corner Brace L-Shaped Metal Bracket Connection.
WPC Panels for Fencing This Workshop Drawing Shows 20mm Thick WPC Panels for Outdoor Fencing: WPC Tongue and Groove Interlocking Panels 1800 x 160mm wide, stacked horzontally on top of each other. 20mm Thick WPC Panel 1800x160mm Wide 20mm Thick WPC Panel 1800x155mm Wide Slide the Panels Down the Slots / Channels Between Two …
Post Caps for Aluminium Posts – WPC Fence Fabrication Drawing for Fence Post Cap: Aluminium Post Caps (Square Profile). Post caps are usually made from powder-coated aluminium, WPC, PVC, HDPE, galvanized or stainless steel. Pyramid roofed cap: Internal diameter 80x80mm External Diameter 84x84mm Base Height 35mm Roof Height 20mm Overall Height 55mm Overall Height …
Aluminium Post Cross Section – WPC Fencing This Fabrication Drawing Shows an Aluminium Post with Square Profile, Overall Cross Section Size 80x80mm with Slots or Channels on Three Faces 22mm Wide and 19mm Deep, for Supporting a 20mm Thick WPC Channel. Cross Section Size: 80×80 mm Channel Width: = 22 mm Channel Depth: = 19 …
Outdoor WPC Fence – Foundation Details The civil engineering drawing shows the cross section details of a WPC Fence Foundation. Aluminium posts embedded in concrete, a minimum depth of 610mm below ground level. Concrete footings 305x305x810mm deep, cast-in-situ against excavated ground, laid over a hardcore layer of gravel (G4 or G5 material) 100 to …
Ground Excavation Plan For WPC Fence Post – Section Details The civil engineering drawing shows an excavation plan for WPC Fencing Post foundations. Excavated holes size 305mm in diameter or 305x305mm square profile, Minimum depth 610 to 914 mm. Holes at suitable centre to centre spacing, for example 1800mm apart. Before excavation, mark the …
WPC Fence Cross Section Details and Elevations [Underground Embedded Posts Installation Method] Installation Method — Underground Embedding. Application: WPC fence panels supported by vertical aluminium posts, with top and bottom horizontal aluminium rails, L-shaped corner braces and cast-in-situ concrete post footings. WPC FENCE INSTALLATION — CONSTRUCTION DETAILING INFORMATION Reference Levels and Datum …
Frost Protected Shallow Footing for Raft Foundation Details – Cross Section and Isometric Plan Dimensioning and Setting-Out Specification – Drafting Reference Notes Frost Protected Shallow Foundation (FPSF) Raft Foundation Detail 3. Reference Levels and Datums These establish where dimensions are measured from. Primary Vertical Reference Ground Level (GL) = 0′-0″ (0 mm) All …
